Positioning the Lifter on the Load

Make certain that the contact surfaces of the load and all vacuum pads are free of any

contaminates that could prevent the pads from sealing against the load (see MAINTENANCE:
V

ACUUM

P

AD

M

AINTENANCE

).

Center the lifter’s pad frame to within 2" [5 cm] of the load center, since off-center loading can

interfere with the lifter’s tilt capability (see T

O

T

ILT THE

L

OAD

to follow), and it may also damage

the lifter.

5

Make sure that all activated pads will fit entirely on the load’s contact surface (see

SPECIFICATIONS: Pad Spread) and that they will be loaded evenly while lifting (see

SPECIFICATIONS: Per-Pad Load Capacity). Then apply the lifter to the load so that all activated
pads are touching the contact surface.

Sealing the Pads against the Load

Turn the apply/release switch on the movable control pendant to the “APPLY” position

(clockwise). This engages the vacuum pumps, causing air to be drawn immediately at the
vacuum pads. Press the lifter onto the load until the pads seal against it. The apply/release
switch must remain in the “APPLY” position throughout the entire lift.

WARNING: Keep apply/release switch in “APPLY” position throughout lift.

Note: If a vacuum pad has been lying against a hard object (as during shipping), it may be
slightly distorted. Although initially it may be difficult to apply the pad to a load, this condition

should correct itself with continued use.

WARNING: Do not disconnect control pendant during lifter operation.

The movable control pendant is not intended to be disconnected during lifter operation.

Disconnecting the control pendant is likely to result in a load release and injury to the operator or
others nearby.

Reading the Vacuum Gauge

The vacuum gauge indicates the current vacuum level in the lifter’s vacuum system. The

green

range indicates vacuum levels sufficient for lifting the maximum load weight, whereas the

red

range indicates vacuum levels that are

not

sufficient for lifting the maximum load weight. The

gauge needle should show a sudden surge in vacuum as the vacuum pads seal against the load.
If it takes more than 5 seconds for the vacuum level to reach 5" Hg [-17 kPa], press on any
activated pad that has not yet sealed.

5

The lifter is designed to handle the maximum load weight (see SPECIFICATIONS: Maximum Load Capacity) when the load’s

center of gravity is positioned within 2" [5 cm] of the pad frame’s center point. Occasional loading deviations are permissible,

provided that the operator can maintain control of the load at all times and that the load weight is low enough to avoid damaging
the lifter.
