Operating features – Wood’s Powr-Grip PT10FS10TAC User Manual
Page 5
Rev 9.0/1-12
3
PT10HV11FAC: #35142
OPERATING FEATURES
Note: Components featured in the following instructions for assembling, operating or
maintaining the vacuum lifter are underlined on their first appearance in each section.
Standard PT10HV11FAC shown.
1 LIFT BAR
7 POWER SWITCH
13 LIFT SHACKLE
2 VACUUM PUMP
8 TILT TOGGLE SWITCH
14 VACUUM RESERVE TANK
3 VACUUM GAUGE
9 PAD SHUTOFF
15 TILT ACTUATOR
4 AIR FILTER
10 VACUUM PAD
16 Enclosure with
5 CONTROL HANDLE
11 VACUUM RELEASE BUTTON
VACUUM SWITCH
6 VACUUM LIFT LIGHT
12 PAD FRAME
