Rev 25.0/5-14

3

MT-FS10TAIR: #35090

SPECIFICATIONS

Description:

Designed for use with a crane or other hoisting equipment, MT-FS10TAIR lifters employ
vacuum to hold a load for lifting, and they provide manual 90° tilt movement for load
manipulation.

Model Number:

MT4FS10TAIR

MT6FS10TAIR

MT8FS10TAIR

MT10FS10TAIR

(4 Vacuum Pads)

(6 Vacuum Pads)

(8 Vacuum Pads)

(10 Vacuum Pads)

Maximum Pad Spread:

1

11¾" x 53¾"

11¾" x 77¾"

21¾" x 77¾"

33¾" x 77¾"

(to outer edges)

[298 x 1365 mm]

[298 x 1975 mm]

[551 x 1975 mm]

[859 x 1975 mm]

Lifter Weight:

87 lbs [40 kg]

101 lbs [46 kg]

112 lbs [51 kg]

125 lbs [57 kg]

Load Capacity:

(rated at 16" Hg [-54 kPa] on clean, smooth, nonporous flat surfaces

2

)

Per-Pad:

150 lbs [68 kg]

150 lbs [68.5 kg]

150 lbs [68.5 kg]

150 lbs [68 kg]

Maximum:

600 lbs [270 kg]

900 lbs [410 kg]

1200 lbs [545 kg]

1500 lbs [680 kg]

Power Source:

Compressed air, 80-150 psi [550-1035 kPa] line pressure, 5 SCFM [142 liters/minute] @
80 psi [550 kPa]

Vacuum Pads:

10" [25 cm] nominal diameter (Model VPFS10T), standard rubber, spring-mounted (¼"
[7 mm] travel), with #60 filter screen and replaceable sealing rings for applications on
rough or textured surfaces.

Pad Shutoffs:

Manual valves control vacuum flow at adjacent pads.

Tilt Capability:

Manual, 90°

Vacuum Pump:

Venturi type, 3 SCFM [85 liters/minute] nominal vacuum flow @ 80 psi [550 kPa]

Vacuum Reserve:

Vacuum reserve system helps prevent immediate vacuum loss in case of power failure.

Vacuum Gauge:

Dial gauge indicates current vacuum level in positive inches of Hg and negative kPa.

Options:

Available

with Model LB4CSO - Center Spool Lift Bar. By eliminating the need for slings

or other rigging, this option allows the hook of hoisting equipment to attach directly to

the lift bar of the vacuum lifter, thereby reducing the overhead clearance requirement.
See separate instructions about other optional features.

Operating Elevation:

Maximum = 10,000 feet [3048 meters]

Operating Temperatures: 0° to 120° F [-18° to 49° C]

Service Life:

This lifter is designed to have a service life of at least 20,000 lifting cycles, when used

and maintained as intended. Vacuum pads, filter elements and other wear-out items
are excluded; see MAINTENANCE and REPLACEMENT PARTS LIST for more information.

For the D

ISPOSAL OF THE

L

IFTER

after its service life, see INTENDED USE.

ASME Standard BTH-1:

Design Category "B", Service Class "0" (see www.powrgrip.com for more information)

!!-CE-!! Note: This symbol appears in the

INSTRUCTIONS

manual only when requirements of a CE Standard are

different

from requirements of other standards that also apply to this vacuum lifter. CE requirements are mandatory

in geographical areas where CE Standards apply, but may be optional in other locations.

1

Minimum Pad Spread is 11¾" x 23¾" [298 mm x 603 mm] for all standard lifters.

2

Load Capacity is based on a friction coefficient of 1; see MAINTENANCE: V

ACUUM

P

AD

M

AINTENANCE

: Friction Coefficient for

additional information.
