HFH/V6000: #35000:
OPERATING FEATURES
Note: Components featured in the following instructions for assembling, operating or
maintaining the vacuum lifter are underlined on their first appearance in each section.
Standard HFH6000 shown.
1 LIFT BAIL
3 HAND CUP with VACUUM PAD
6 TILT RELEASE LEVER
2 LIFT BAR
4 PAD FRAME
7 CONTROL HANDLE
5 ROTATION RELEASE LEVER
