Wood’s Powr-Grip HFV6000 - Manual (Page 5)

Rev 12.0/12-13 3 HFH/V6000: #35000:
SPECIFICATIONS
Description: Designed for use with a crane or other hoisting equipment, HF
Series lifters employ vacuum to hold a load for lifting, and they
provide manual 180° rotation and manual 90° tilt movements for
load manipulation.
Model Number:
Horizontal Configuration: HFH6000
Vertical Configuration:
HFV6000
Load Capacity: 1 (rated on clean, smooth, nonporous flat surfaces 2 )
Per-Pad: 116 lbs [53.5 kg]
Maximum: 700 lbs [320 kg]
Lifter Weight: 1 75 lbs [34 kg]
Pad Spread: 1 (to outer edges)
Horizontal Configuration: 46" x 57" [1169 mm x 1448 mm]
Vertical Configuration:
57" x 46" [1448 mm x 1169 mm]
Rotation Capability: Manual, 180°, with automatic locking at each ¼ revolution (when
desired)
Tilt Capability: Manual, 90°, with automatic locking in vertical position
Operating Elevation: Red-line vacuum indicator on hand cups may not perform reliably
at elevations above 5000 ft [1524 m]; contact Wood’s Powr-Grip
or an authorized dealer for assistance before using the lifter at
such elevations.
Operating Temperatures: 10° to 120° F [-12° to 49° C]
Service Life:
This lifter is designed to have a service life of at least 20,000
lifting cycles, when used and maintained as intended. Vacuum
pads and other wear-out items are excluded; see MAINTENANCE
and REPLACEMENT PARTS LIST for more information. For the
D
ISPOSAL OF THE
L
IFTER
after its service life, see INTENDED USE.
ASME Standard BTH-1: Design Category "B", Service Class "0" (see www.powrgrip.com
for more information)
!!-CE-!! Note: This symbol appears in the INSTRUCTIONS manual only when requirements of a CE Standard are
different from requirements of other standards that also apply to this vacuum lifter. CE requirements are mandatory
in geographical areas where CE Standards apply, but may be optional in other locations.
1
Specifications apply to lifters using Wood's Powr-Grip N5450 (9" [23 cm] diameter) hand cups. If another size hand cup is
used, consult the manufacturer for specifications.
2
Load Capacity is based on a friction coefficient of 1; see MAINTENANCE: V
ACUUM
P
AD
M
AINTENANCE
: Friction Coefficient for
additional information.
