7
2. SPECIFICATIONS
2.1 Model Specifications
2.1.1 Supertitan
Model
Number
Travel
(in) Lifting
Capacity
Max.
End
Load
Capacity
(lbs) Max.
Side
Load
Capacity
(lbs)
Base
and Min.
Platform
Size (in) Minimum
Lowered
Height
(in) Maximu
m
Platform
Size (in)
Std
Speed
(sec.)
App.
Ship
Wt.
(lbs.)
24K18 24 18,000 18,000 18,000 42 x 60 12 1/2 72 x 96 12 3,000
24L20 24 20,000 20,000 20,000 42 x 60 15 1/2 72 x 96 15 3,150
24K27 24 27,000 18,000 18,000 42 x 60 12 5/8 72 x 96 18 3,200
24L31 24 31,000 23,000 23,000 42 x 60 15 5/8 72 x 96 22 3,350
36KK15 36 15,000 12,000 12,000 42 x 84 12 1/2 72 x 120 21 3,750
36LL21 36 21,000 16,000 16,000 42 x 84 16 1/8 72 x 120 23 4,000
36KK24 36 24,000 12,000 12,000 42 x 84 12 1/2 72 x 120 32 4,050
36LL32 36 32,000 16,000 16,000 42 x 84 16 1/8 72 x 120 37 4,300
36MM40 36 40,000 22,000 22,000 42 x 84 19 3/8 72 x 120 41 4,450
48KK15 48 15,000 12,000 12,000 42 x 84 12 1/2 72 x 96 29 3,750
48LL21 48 21,000 16,000 16,000 42 x 84 16 1/8 72 x 96 33 4,000
48KK24 48 24,000 12,000 12,000 42 x 84 12 1/2 72 x 96 44 4,050
48LL32 48 32,000 16,000 16,000 42 x 84 16 1/8 72 x 96 49 4,300
48MM40 48 40,000 22,000 22,000 42 x 84 19 3/8 72 x 96 44 4,450
60KK14 60 14,000 12,000 12,000 42 x 84 12 1/2 60 x 96 36 3,750
60KK24 60 24,000 12,000 12,000 42 x 84 12 1/2 60 x 96 55 4,050
60R28 60 28,000 16,000 16,000 42 x 112 18 3/4 72 x 144 57 5,450
72O10 72 10,000 8,000 8,000 42 x 112 12 1/2 72 x 144 38 4,600
72LL15 72 15,000 11,000 11,000 42 x 112 15 1/2 72 x 144 39 4,900
72LL24 72 24,000 11,000 11,000 42 x 112 15 1/2 72 x 144 56 5,200
84LL12 84 12,000 9,000 9,000 42 x 132 15 1/2 72 x 168 37 5,600
84LL20 84 20,000 9,000 9,000 42 x 132 15 1/2 72 x 168 55 5,900
96LL11 96 11,000 8,000 8,000 42 x 150 15 1/2 72 x 180 42 6,200
96LL18 96 18,000 8,000 8,000 42 x 150 15 1/2 72 x 180 58 6,500
120LL6 120 6,000 6,000 6,000 42 x 186 15 1/2 72 x 222 40 7,500
120LL11 120 11,000 6,000 6,500 42 x 186 15 1/2 72 x 222 58 7,800
