NC-2200W WIRELESS SETTING 2 - 11

NC9100h_FM6.0

You can see the Network name (SSID/ESSID) of the NC-2200w
in the Available wireless networks box. Select SETUP and
check the Allow me to connect... check box. Click the
Connect button.

Check the wireless network connection status. It may take a few
minutes to change from 0.0.0.0 to 169.254.x.x IP address to be
shown on screen. (where x.x are numbers between 0 and 255).

If the Network name (SSID/ESSID) you want to choose is not
listed, try the following:

■

Unplug the AC adapter, plug it back in again and then wait for a
few minutes.

■

Move your Brother Printer/MFC/DCP with the NC-2200w
installed closer to your computer and try again.

■

Reset the NC-2200w back to its default factory settings and try
again. For the information how to reset to the factory default
setting see

Test Button

on page 1-4.

■

Refer to Chapter 6 of the NC-2200w Network User’s Guide on the
CD-ROM we have supplied with the NC-2200w.
