A
PPENDIX
A
:
C
YCLE
T
IMES
F
OR
F
UNCTIONS
1. Position the handler safely, in a level, open area, well away from traffic lanes, buildings, other
equipment or personnel.
2. Position the handler so that all cylinders may bottom out in both directions.
3. Run the engine at full throttle (2500 RPM) during testing.
C-Series Cycle Times
D-Series Cycle Times
NOTE!
Use these charts to help determine the condition of the Main Implement Pump.
FUNCTION
522 & 524
532C-6 & 534C-6
534C-9 & 53
Boom Up (fully retracted)
10.00
14.00
12.00
Boom Down (fully retracted)
7.00
10.25
10.00
Boom Extend (level)
7.00
10.75
12.50
Boom Retract (level)
10.00
14.00
13.50
Attachment Tilt Up
3.00
3.25
3.00
Attachment Tilt Down
3.50
3.75
3.50
TIME
(seconds)
FUNCTION
522D & 524D
534D-6
534D9-42
534D-9 & 534D-10
534D
Boom Up (fully retracted)
10.00
14.00
14.00
12.00
Boom Down (fully retracted)
7.00
10.25
11.50
10.00
Boom Extend (level)
7.00
10.75
13.50
12.50
Boom Retract (level)
10.00
14.00
15.00
13.50
Attachment Tilt Up
3.00
3.25
3.25
3.00
Attachment Tilt Down
3.50
3.75
3.75
3.50
TIME
(seconds)
