SPECIFICATION SHEET
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
REFERENCE
QTY.
REMARKS
Project
Location
Architect
Engineer
Contractor
Submitted by
Date
KICKSPACE HEATERS
MODELS 112 & 114
Low-profile design provides floor-level heat from
out-of-the-way locations.
FEATURES
•
Attractive white finish
•
Vertical louvers – disperse heat evenly
•
Front-mounted, snap action, bimetallic thermostat (Model
112 only)
•
Heavy-duty, steel sheathed, plate-finned element
•
Factory-wired for 240 VAC, 1500W
•
Field-convertible to operate on 120 VAC, 750 or 1500W
•
Mounts into standard kickspaces beneath cabinets, vanities,
counters, stairways, etc.
ACCESSORIES (purchase separately)
•
Model 86W Line-Voltage Thermostat
•
Model 59W / 59V 60 Minute Timer
•
Model 61W / 61V 15-Minute Timer
•
Model 90 Built-in Thermostat Kit (Model 114 only)
TYPICAL SPECIFICATION
The heater shall be Broan Model 112 (Model 114).
Unit shall have heavy-gauge steel housing and grille with
white finish.
Heater will have heavy-duty, steel-sheathed, plate-finned
element. Heater will have front-mounted thermostat (Model
112 only).
Heater to deliver 1500 watts of fan-forced heat from 240 VAC
circuit. It must be convertible to operate on 120 VAC, full or
half-wattage.
Heater shall be U.L. Listed.
Model 112
SPECIFICATIONS
SHIPPING
VOLTS
WATTS
AMPS BTU/HR
WEIGHT
240
1500
6.2
5120
120
750
6.2
2560
12 lbs.
208
1125
5.4
3840
120
1500
12.5
5120
BOLD ratings are factory-wired.
01C
99041277E
