COOLANT SCHEMATIC ULTRA-1
COPPER TUBE .25” O.D. X .030”
COPPER TUBE .25” O.D. X .030”
SUCTION
ACCUMULA
TOR
COPPER TUBE
.312” O.D. X .032”
CONDENSER
EV
APORA
TOR
FIL
TER DR
YER
COMPRESSOR
SERVICE
VA
LV
E
FOR COOLANT CHARGE INFORMA
TION SEE DECAL
ON SIDE P
ANEL
SERVICE
VA
LV
E
FOR COOLANT CHARGE INFORMA
TION SEE DECAL
ON SIDE P
ANEL
TO CONTROL BOARD
THERMISTOR TEMPERA
TURE SENSOR
SOLENOID
VA
LV
E
ELECTRONICALL
Y
CONTROLLED
CAP TUBE
