unDX2IO
User Manual
Attero Tech LLC 2013
Page 5
614-00016-01
2 – Device Installation
1
2
3
1
Power/ ID LED
2
2 x Balanced audio inputs
3
2 x Balanced Audio outputs
*Note:
The unDX2IO has a label on the front of the metal housing at the top that shows the last 6 digits of the MAC
address. This is important for initial device identification as these digits make up part of the devices default network
name that is shown when the device is detected by Dante Controller. The full MAC address is also given on the back of
the unit.
