Attero Tech unDX2IO - Manual (Page 4)

unDX2IO
User Manual
 Attero Tech LLC 2013 Page 3 614-00016-01
Contents
1 - Overview .....................................................................................................................................................................................................................4
1.1 – What’s in the Box ..................................................................................................................................................... 4
2 – Device Installation.................................................................................................................................................................................................5
2.1 – Mounting .................................................................................................................................................................. 6
2.2 – Hardware Connections ............................................................................................................................................. 6
2.2.1 – Input from an Unbalanced Source ................................................................................................................... 6
2.2.2 – Input from a Balanced Source .......................................................................................................................... 7
2.2.3 – Output to a Balanced Destination.................................................................................................................... 7
2.2.4 – Output to an Unbalanced Destination ............................................................................................................. 7
3 – Device Configuration ...........................................................................................................................................................................................8
3.1 – Software Installation................................................................................................................................................. 8
3.2 – Device Configuration.............................................................................................................................................. 10
3.2.1 – Selecting a Network Adapter ......................................................................................................................... 10
3.2.2 – Connecting to a Device .................................................................................................................................. 10
3.2.3 – Device Identification ...................................................................................................................................... 10
3.2.4 – Device Controls .............................................................................................................................................. 11
3.2.5 – Saving and Loading Settings.......................................................................................................................... 11
3.2.5.1 – Internal Presets ...................................................................................................................................... 11
3.2.5.2 – Preset Files ............................................................................................................................................. 11
4 – ARCHITECTS & ENGINEERS SPECIFICATION ........................................................................................................................................... 12
4.1 – Device Specifications.............................................................................................................................................. 12
APPENDIX A - Reference Documents............................................................................................................................................................... A-1
