The glasswasher is shipped in one carton. Please refer to Figure 1 and locate the following items:
T
he ITems are
:
a
ssembly
o
rder
d
escrIpTIon
1 Bolt the legs to the base of
the Main Section.
2 Remove all packaging from
the Main Section.
3 Remove plastic protective
paper from all stainless steel
parts. This may require
removing side panels.
4 Place glasswasher in position
and level by adjusting the bot-
tom portion of the stainless legs.
5 Make plumbing and electrical
connections (see page 8).
a
ssembly procedures
:
I
Tem
n
umber
d
escrIpTIon
1 Main Section
2 Stainless Steel legs (4)
3 Conveyor
4 Front Curtain
5 Wash Curtain
6 Rinse Curtain
7 Front Shield
8 Top Section
n
oTe
: Figure 1 shows a clockwise model with front switch panel.
F
IGure
1
u
ncraTInG
I
nsTrucTIons and
e
quIpmenT
c
hecklIsT
2
1
4
3
5
8
7
6
