10 Programming
1 Activation of the display Display the decimal places 5 - 8 by pushing or. after switching on.
2 Change menu level With in the top menu level, i.e. change from measuring mode into the main menu
or from the main menu to the sub menu.
3 Select menu items Select with or the desired menu item (see chapter 11).
4 Activate menu item
Value input/Function
selection Activate the desired menu item with , to change the corresponding value or the
desired function.
5 Change value Select the individual digits with .
Change the numerical value with or and acknowledge with .
If the entered value is within the permissible range, the system changes to the menu
item after input and acknowledgement of the last digit, otherwise the 1st digit will flash
again.
6 Change function Change the function with or and acknowledge with .
Return to the main
menu Leave the last item of the sub menu with . You will automatically return to the main
menu.
Activate key lock Press + for at least 5 s simultaneously. The display must not change.
Key lock active Values or functions will be displayed but cannot be changed. will be displayed
when attempting a change.
Deactivate key lock Press + for at least 5 s simultaneously. The display must not change.
Return to measuring
mode If no entry is made for 2 minutes, the switch automatically returns to the measuring
mode without accepting the entries.
Terminate programming Press for at least 5 s to change to the measuring mode.
11 User Level Dialog
Main menu Sub menu Value Function/Description
Measuring mode uring value and the unit of the .... .... Display the actual meas
measuring value
Display programming lock
no lock: all settings can be changed
unit is locked: no settings can be changed
Display Menu
Selecting the display units
Activation of the unit display
Flow (Flou) or Volume (voL) display
Press + for at least 5 sec to change into the
volume display.
Dialog User Level (continued)
Main menu Sub menu Value Function/Description
Switchpoint menu SP1 ... SP2
Standard evaluation (rising/falling)
window technology
error output
Dosing mode (when measuring volume)
.... Switch-on value for SP1...SP2
if the ON-value is smaller than the OFF-value,
the switch evaluation is falling
.... Switch-off value for SP1...SP2
0.0 s ... 99.9 s Startup delay (0 = deactivated)
Inversion of switching output
high-level-fail-safe (normally open function)
low-level-fail-safe (normally closed function)
0.0 s ... 9.9 s Switch-on delay for SP1 [s]
0.0 s ... 9.9 s Switch-off delay for SP1 [s]
0.0 s ... 9.9 s Switch-on delay for SP2 [s]
...
0.0 s ... 9.9 s Switch-off delay for SP2 [s]
Analog output menu
Analog output in operation
Analog output switched off
.... Scale the analog output - start value (e. g. 0
l/min = 4 mA)
.... Scale the analog output - end value (e. g. 40
l/min = 20 mA)
if available
Pulse output menu
Flow mode
Volume mode
.... Scale frequency output value
.... Scale frequency at end value
.... Volume per pulse
