Protocols Supported
The Touring Edition supports:
ArtNet
Pathport xDMX Protocol
Strand Shownet
ETC Net2 eDMX (output only)
Streaming ACN (E1.31 sACN)/ETC Net3
The Touring Edition also supports RDM (E1.20 Remote Device Management) as a
controller device. The TE can discover RDM-enabled responders and can report and
reconfigure the DMX start address for those devices.
The TE supports the current DMX standard E1.11 DMX512-A and is backwards
compatible to USITT DMX512 (1990).
Features Supported
The Touring Edition has similar functionality to all other Pathport one-port nodes:
- address up to 128 universes
- discover up to 128 RDM devices
- output patch can be customized to merge/prioritize up to eight input sources
- output patch is definable on a channel-by-channel basis
- DMX output speed is user selectable
- signal loss behavior is user-definable
- cross-fade between inputs on loss of signal within a user-defined time
- will operate on any valid IP address/subnet combination
The Touring Edition also supports these testing features:
- reports incoming and outgoing DMX levels
- DMX output test drives user-selected channel levels up and down
- performs discovery and start address editing of RDM-enabled devices
Installation
The Touring Edition ships with a rear-mounted hanging bracket which will accept a ½”
(12.5mm) bolt, and is intended to be suspended using a standard C-Clamp or similar pipe
hanger. A separate anchor point is provided for a secondary safety. The hanging bracket
may be rotated in 90 degree increments.
The TE has an IP54 enclosure rating when mounted so that the cable connections
point straight down.
