550 & 950Air Spinmaster Hose

1

2

3

4

5

Part Name

Qty.Per Unit

Item

Part #

Hydraulic Hose (top rod to bottom rod)

Hydraulic Hose (top piston to bottom piston)

Air Hose (air valve to air motor)

Hydraulic Hose (bottom rod to valve)

Hydraulic Hose (bottom piston to valve)

1

1

1

1

1

1

2

3

4

5

Part Name

Qty.Per Unit

Item

Part #

Hydraulic Hose (top rod to bottom rod)

Hydraulic Hose (top piston to bottom piston)

Air Hose (air valve to air motor)

Hydraulic Hose (bottom rod to valve)

Hydraulic Hose (bottom piston to valve)

1

1

1

1

1

1

2

3

4

5

031-24738-8

031-24738-13

031-1-1/4x50"

031-24738-5

031-24738-6

550 Air Spinmaster

950 Air Spinmaster

031-24738-8

031-24738-8

031-1-1/4x42"

031-24738-5

031-24738-6

Drawings
