Setting Up the TV
27
Se
tting
Up the
TV
KDX-46Q005
2-592-150-12(2)
Installing the Media
Receiver Unit
Vertically When you install the media receiver unit vertically, use the supplied stand for
vertical installation. Attach the stand to the right side of the media receiver
unit. When you attach the stand, use the edge of a desk or a table, as shown
below.
1
Remove the two small screws from the right side of the media receiver
unit.
2
Match the two screw holes on the stand to those on the media receiver
unit.
3
Insert the two screws with washers (supplied) into the holes and tighten
them securely.
Media receiver unit
Vertical installation stand
Desk or table
