Page 21
English - 21
JACK PANEL DETAIL / REAR VIEW
1
5
3
2
6
4
(Unit: inches)
Model name
1
2
3
4
5
6
PN43F4500 / PN43F4550
16.8
1.3
2.5
28.4
15.7
15.7
PN51F4500 / PN51F4550
19.5
1.4
3.1
35.0
15.7
15.7
PN51F5300 / PN51F5350
19.5
1.4
3.1
35.0
15.7
15.7
PN60F5300 / PN60F5350
20.4
1.0
6.7
42.0
23.6
15.7
PN64H5000
21.8
1.7
6.9
42.8
23.6
15.7
NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to
the dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors.
© 2014 Samsung Electronics America, Inc
Supported Videos Formats
File Extention
Container
Video Codec
Resolution Frame rate (fps) Bit rate (Mbps)
Audio Codec
*.avi / *.mkv
*.asf / *.wmv
*.mp4 / *.3gp
*.vro / *.mpg
*.mpeg / *.ts
*.tp / *.trp
*.mov / *.flv
*.vob / *.svi
*.divx
AVI
MKV
ASF
MP4
3GP
MOV
FLV
VRO
VOB
PS
TS
DivX 3.11/4/5/6
1920 x 1080
6~30
30
AC3
LPCM
ADPCM
(IMA, MS)
AAC
HE-AAC
WMA
DD+
MPEG
(MP3)
DTS (Core)
G.711(A-Law,
μ-Law)
MPEG4 SP/ASP
H.264 BP/MP/HP
Motion JPEG
640 x 480
8
Window Media Video v9
1920 x 1080
30
MPEG2
MPEG1
✎
Other Restrictions
• Video content will not play, or not play correctly, if there is an error in the content or the container.
• Sound or video may not work if the contents have a standard bit rate/frame rate above the compatible Frame/sec
listed in the table above.
• If the Index Table contains an error, the Seek (Jump) function is not supported.
• Some USB/digital camera devices may not be compatible with the TV.
• The menu may display slowly if the video you are watching has a bit rate over 10Mbps.
