Phottix Trafo Junior - Manual (Page 3)

1. Align two rods. Slide Camera Mount onto rods and tighten
screws
2. Attach Z Bracket and rods. Tighten screws. Push Shoulder
Pad onto the rods
3. Snap Follow Focus assembly onto rods and tighten screw.
Trafo Jr Assembly Instructions
3
2
1
EN
Included Parts:
88355 Phottix Trafo Follow Focus System x1
88361 Crossbar Adapter x1
88365 Camera Mount and Plate x1
88368 LCD Attachment Adapter x1
88369 LCD Attachment Arm (Short) x1
88375 Z bracket x1
88364 Shoulder Pad x1
88380 Carbon Fiber-AL Rods 21cm x2
88381 Carbon Fiber-AL Rods 27cm x3
88360 Front Handles x2
