n Place the 373XXA on its right side (monitor down).
n If not already done, remove the feet from the two
left-side corners at the rear of the 373XXA.
n Remove two center screws from the left cover.
n Remove the center screw from rear of the left side cover.
n Lift and slide the side cover away from the 373XXA.
Step 5. To remove the right cover:
n Place the 373XXA its left side (monitor up).
n If not already done, remove the feet from the two
right-side corners at the rear of the 373XXA.
n Remove the center screw from rear of the right side
cover.
n Remove the center screw from rear of the right side
cover.
n Lift and slide the side cover away from the 373XXA.
To replace the instrument covers, perform the steps above in the re-
verse order.
REMOVE AND REPLACE COVERS
373XXA MM 8-5
Figure 8-1. Exploded View of 372XXB Chassis Covers
