3.7 PC Health Status
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
►
ABIT FanEQ Control Press Enter Item Help
FAN Fail Alarm Selectable Disabled
Shutdown When FAN Fail Disabled
CPU Shutdown Temperature Disabled
CPU Warning Temperature 85
°C/ 185°F
CPU Temperature 35
°C/ 95°F
System Temperature 32
°C/ 89°F
PWM Temperature 35
°C/ 95°F
CPU FAN Speed 3245 RPM
SYS FAN Speed 4218 RPM
AUX1 FAN Speed 0 RPM
AUX2 FAN Speed 0 RPM
CPU Core Voltage 1.25V
DDR2 Voltage 1.88V
DDR2 VTT Voltage 0.93V
PCIe Voltage 1.75V
ATX +12V 11.98V
ATX +5V 5.20V
ATX +3.3V 3.29V
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ABIT FanEQ Control
This item determines the temperature threshold to raise the fan attached at CPU and SYS fan
headers up to their full speed.
Click key to enter its submenu:
Phoenix – AwardBIOS CMOS Setup Utility
ABIT FanEQ Control
CPU FanEQ ontrol Enabled Item Help
- FanEQ Target Temp. 50
°C/122°F
- FanEQ Temp. Tolerance 5
°C/ 41°F
- FanEQ Start Control 80%
- FanEQ Stop Control 50%
SYS FanEQ Control Enabled
- FanEQ Target Temp. 35
°C/ 95°F
- FanEQ Temp. Tolerance 5
°C/ 41°F
- FanEQ Start Control 70%
- FanEQ Stop Control 50%
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
3-22 iL-90MV
