Page 42
※ The option [Enhanced Mode] does not support the Windows 98/ME operating
system.
-
PATA IDE Mode
This item determines the function mode for “IDE1”connector.
[IDE-1]: “IDE1” connector served as [Primary Master] and [Primary Slave] channel. The
remaining “SATA1” and “SATA2” connectors are disabled.
[IDE-2]: “IDE1” connector served as [Secondary Master] and [Secondary Slave] channel.
“SATA1” and “SATA2” connector served as [Primary Master] and [Primary Slave] channel.
Refer to the following table for the relationships between IDE and SATA ports.
PATA IDE
Mode
IDE Channel 1
Master
IDE Channel 1
Slave
IDE Channel 2
Master
IDE Channel 2
Slave
IDE-1
IDE Master
IDE Slave
None
None
IDE-2
SATA1
SATA2
IDE Master
IDE Slave
※ This option is configurable only when the item [On-Chip SATA Controller] is set
to [Combined Mode].
On-Chip PCI Device
Click
Phoenix – AwardBIOS CMOS Setup Utility
On-Chip PCI Device
On-Chip USB Controller
Enabled
Item Help
- USB 2.0 Controller
Enabled
- USB Keyboard Support via
OS
- USB Mouse Support via
OS
On-Chip Audio Controller
Enabled
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
On-Chip USB Controller
This option enables or disables the USB controller.
3-14
iL-90MV
