Brother HL-4200CN - Manual (Page 42)

NOVELL NETWARE PRINTING 6 - 4
Creating Print Queue Object
3
Click the Create button. The Input Name dialog box is displayed.
4
If Context is correctly set, enter the printer name in the Queue Name field, and click the OK button.
Example: BRN_4000F4-Q
5
Click the Select button on the right of Queue Volume box.
6
In the Select Object dialog box, select the volume of the created object, and then click the OK
button.
7
Check that the selected object name is displayed in Queue Volume of the Input Name dialog box,
and then click OK.
The Print Queue name will be entered in Queue of the NetWare Print Environment Settings dialog box.
8
When the print server, printer and queue are all set, click the OK button.
You can specify users that can be connected to the queue by clicking the User button.
9
Check that the settings specified in the NetWare Print Environment Settings dialog box are entered
in the NetWare tab of the Configure dialog box as follows:
Example:
10
Click the NetWare Control tab.
11
Enter the required item and click the OK button.
12
When you use Remote Printer mode, reboot the NetWare print server on the NetWare file server.
Configuring in Bindery Service
We have to create the print server, printer, and each object of the queue for this printer on the NetWare
file server.
1
Click Print Environment Settings.
Item Queue Server Mode Remote Printer Mode
Print Server Name BRN_4000F4 CLEVER-PS (selected from
already existing print server)
Remote Printer Name --- BRN_4000F4-P
NDS Tree Name BRTREE BRTREE
Context Name 0U=SALES.
0=BROTHER 0U=SALES.
0=BROTHER
