INOR MINIPAQ-L GB - Manual

MEASURE OF SUCCESS
Intelligent, Economy
2-wire Transmitter
86BMQ00008 2009-01
GENERAL INFORMATION
MinIPAQ-L is a basic, programmable, non-isolated, easy-to-use
2-wire temperature transmitter intended to be used in industrial
environment.
The transmitter is configured from a PC via a USB port, connected
via the INOR USB Interface, by using the ConSoft program together
with the MinIPAQ Soft program.
When the transmitter is set from a PC no calibration is needed.
ConSoft is compatible with Windows 2000 (SP3), Windows XP and
Windows Vista (32-bit).
All necessary hardware and software for configuration are included
in the ICON Configuration Kit, 70CFGUS001.
USER INSTRUCTIONS
The user instruction must be read prior to adjustment and/or installation.
All information subject to change without notice.
MEASURE OF SUCCESS
This product should not be mixed with other kind of scrap, after usage.
It should be handled as an electronic/electric device.
www.inor.com, www.inor.se
INOR Process AB, PO Box 9125, SE-200 39 Malmö, Sweden,
Phone: +46(040)31 25 60, Fax: +46(040)31 25 70, E-mail: [email protected]
INOR Transmitter OY, Unikkotie 13, FI-01300 Vantaa, Finland,
Phone:+358-10-4217900, Fax: +358-10-4217901, E-mail: [email protected]
INOR Transmitter GmbH, Rodenbacher Chaussee 6,
DE-63457 Hanau-Wolfgang, Germany,
Phone: +49(0)6181-582940, Fax: +49(0)6181-582944, E-mail: [email protected]
INOR Transmitter Inc, 7 Dearborn Road, Peabody, MA 01960, USA,
Phone: +1(978) 826-6900/(262) 670-9050,
Fax: +1(978) 535-3882/(262) 670-9001, E-mail: [email protected]
CONFIGURATION
Guidelines for ConSoft version 1.1.0.2 or higher.
Before making a configuration of MinIPAQ-L you need to do
following:
1. Install the drivers for the INOR USB Interface.
2. Install the PC configuration software ConSoft in your PC.
3. Install the PC configuration software MinIPAQ Soft, version 1.24.00 or
higher, in your PC.
Please refer to “Installation Guide for ICON”, 86BCONF004, for
detailed installation instructions. All software and guides are included in the
ICON Configuration Kit, 70CFGUS001, and can also be downloaded from the
web site www.inor.com.
Configuration procedure:
The help files in ConSoft and MinIPAQ Soft contains complete information
about the configuration procedure. Here is a short-form guide:
1. Connect the MinIPAQ-L to the PC via the USB Interface.
Configuration can be performed with or without connected power
supply.
2. In ConSoft, click on the upper left “Read from transmitter” button.
The software will automatically recognize the connected transmitter
and open the MinIPAQ Soft program. The MinIPAQ Soft program
will automatically find the correct communication port (first time
MinIPAQ Soft is used it will open the Com port selection window).
3. In the configuration window you can set the following parameters:
a. Input (RTD or Thermocouple type)
b. 3- or 4-wire connection (for RTD input)
c. Activation of Cold Junction Compensation (for T/C input)
d. Measuring range in three different engineering units
e. Upscale or downscale action at sensor break or short-circuit
f. Compensation for known sensor errors
g. Activation of a Low pass filter
4. The selected configuration is downloaded to the transmitter by clicking
the button “Transfer to transmitter”. If the transmitter is in operation
during transmission from the PC, the transmitter output is frozen.
When the transfer is complete, the transmitter begins using the new
parameters directly.
DATA (shortform)
Input See ”Input Connections”
Sensor failure Upscale, downscale or off
Adjustments - Zero Any value within range limits
Adjustments - Minimum spans
Pt100, Pt1000, Ni100, Ni120, Ni1000 10°C / 18°F
Cu10 100°C / 180°F
T/C 2 mV
Output 4-20 mA, temperature linear
Operating temperature -20 to +70°C / -4 to +158°F
Galvanic isolation No
Power supply 8 to 32 VDC
Typical accuracy ±0.15 % of temperature span
Mounting Rail acc. to DIN EN 50022, 35 mm
