English
1
First-Time Use
Unpacking Open the receiver box and unpack the following items:
• Receiver
• SD card containing required applications (GNSS Toolbox,
GNSS Service, etc.)
• Battery
• Docking station
• Universal AC adapter
• USB cable
Inserting the
Battery Into the
Receiver
Follow the instructions below:
• Turn over the receiver and rotate the finger screw counter-
clockwise a quarter turn and pull the trap door open.
• Insert the battery as shown. The label must be outwards
and the right way up.
• Put the trap door back into place by first inserting the two
clips located at the top of the trap door.
• Then push the door against the case and rotate the finger
screw clockwise by one-quarter turn for a secure and
sealed closure.
