Pro-Cut PFM 9.0 User Manual
Page 42
PFM-9.05 (220V)
PFM-9.0 (120V)
11
44
32
43
22
41
40
42
17
9
45
14
18
12
13
23
7
5
31
10
6
1
19
20
8
46
15
4
(C) Pro-Cut International LLC, Ltd.
9/4/2012
26
2
37
39
21
34
24
38
33
16
25
29
35
30
36
28
3
27
PFM-9.05 (220V) Shown
*Notes:
1. 220V: 50-9052 120V: 50-9002
2. 220V:50-531, 120V: 50-539
37. 220V: 50-235, 120V: 50-238
46. Includes (2) M8x20 Cap Screws
ITEM
NO.
PART
NUMBER QTY.
1
50-9052*
1
2
50-531*
1
3
50-658
1
4
50-661
1
5
50-570
1
6
50-566
1
7
50-565
1
8
50-564
1
9
50-041
1
10
50-625
1
11
50-651
1
12
37-494
1
13
37-493
1
14
35-411
4
15
35-717
5
16
35-236
4
17
35-289
2
18
37-725
1
19
35-936
2
20
50-560
1
21
50-074
1
22
50-1400
1
23
50-567
1
24
50-1121
1
25
35-925
2
26
50-139
1
27
50-463
1
28
37-070
1
29
50-465
1
30
50-679
1
31
50-568
1
32
50-1165
1
33
50-498
1
34
50-643
1
35
35-926
1
36
50-813
1
37
50-235*
1
38
50-646
1
39
35-269
1
40
50-1826
1
41
50-1110
1
42
50-364
2
43
36-113
1
44
50-837
1
45
50-838
1
46
50-1247*
1
PG /
Ø42
800.543.6618
9.0 DRO PARTS DIAGRAM
PFM-9.0 / PFM-9.05 Parts Diagram
