Pumptec Operating Instructions and Parts Manual
PUMP SERIES 348U | 350U | 356U
NOzzLE PErFOrmANCE CHArt
40
PSI
100
PSI
250
PSI
500
PSI
600
PSI
700
PSI
800
PSI
1000
PSI
1200
PSI
NOzzLE
SizE
ORIRCE
DIA.
THEORETICAl DISCHARgE VOlUME (gPM)
2
0.034
0.20
0.32
0.50
0.71
0.77
0.84
0.89
1.00
1.10
2.5
0.039
0.25
0.40
0.63
0.88
0.97
1.05
1.12
1.25
1.37
3
0.043
0.30
0.47
0.75
1.06
1.16
1.25
1.34
1.50
1.64
3.5
0.048
0.35
0.55
0.88
1.24
1.36
1.46
1.57
1.75
1.92
4
0.052
0.40
0.63
1.00
1.41
1.55
1.67
1.79
2.00
2.19
4.5
0.055
0.445
0.71
1.13
1.59
1.74
1.88
2.01
2.25
2.46
5
0.057
0.50
0.79
1.25
1.77
1.94
2.09
2.24
2.50
2.74
5.5
0.060
0.55
0.87
1.38
1.94
2.13
2.30
2.46
2.75
3.01
6
0.062
0.60
0.95
1.50
2.12
2.32
2.51
2.68
3.00
3.29
6.5
0.064
0.65
1.03
1.63
2.30
2.52
2.72
2.91
3.25
3.56
7
0.067
0.70
1.11
1.75
2.47
2.71
2.93
3.13
3.50
3.83
HOrSEPOwEr CHArt
FLOw iN
gPM
HOrSEPOwEr rEqUirED @ PSi (POUNDS PEr SqUArE iNCH)
50
100
150
200
300
400
500
750
1000
1200
1500
0.2
.006
.012
.018
.023
.035
.047
.058
.088
.117
.140
.175
0.4
.012
.023
.035
.047
.070
.093
.117
.175
.233
.280
.350
0.6
.018
.035
.053
.070
.105
.140
.041
.263
.350
.420
.525
0.8
.023
.047
.070
.093
.140
.187
.233
.350
.467
.560
.700
1
.029
.058
.088
.117
.175
.233
.292
.438
.583
.700
.875
1.2
.035
.070
.105
.140
.210
.280
.350
.525
.700
.840
1.050
1.4
.041
.082
.123
.163
.245
.327
.408*
.613
.817
.980
1.225
1.6
.047
.093
.140
.187
.280
.373
.467
.700
.933
1.120
1.400
1.8
.053
.105
.158
.210
.315
.420
.525
.788
1.050
1.260
1.575
2
.058
.117
.175
.233
.350
.467
.583
.875
1.167
1.400
1.750
2.2
.064
.128
.193
.257
.385
.513
.642
.963
1.284*
1.540
1.925
2.4
.070
.140
.210
.280
.420
.560
.700
1.050
1.400
1.680
2.100
2.6
.076
.152
.228
.303
.455
.607
.758
1.138
1.517
1.820
2.275
(*) NOTE: 1.4 g PM at 500 PSI requires .408 HP.
