HDC-3x Series Video Capture Card
Page 19
NOTE:
The HDC-301 and HDC-301E models have one HDMI output port on
the external peripheral IO panel. There is no need for these two models
to install the HDMI output kit to enable the HDMI output connection.
2.4.1.1 HDC-304E HDMI Output Kit Connector (JR1)
The HDMI output kit connector connects to the HDMI output kit cable that provides an
HDMI output port. Pinouts for the connector are shown in Table 2-2.
Pin No. Description Pin No. Description
1 HDMI_OUT_TX2+ 11 GROUND
2 GROUND 12 HDMI_OUT_TXC-
3 HDMI_OUT_TX2- 13 N/A
4 HDMI_OUT_TX1+ 14 N/A
5 GROUND 15 HDMI_OUT_DCLK
6 HDMI_OUT_TX1- 16 HDMI_OUT_DSDA
7 HDMI_OUT_TX0+ 17 GROUND
8 GROUND 18 VCC_5V
9 HDMI_OUT_TX0- 19 HDMI_OUT_HPD
10 HDMI_OUT_TXC+ 20 N/A
Table 2-2: HDC-304E HDMI Output Kit Connector Pinouts
Figure 2-4 shows the location of the HDMI output kit connector.
