HDC-3x Series SDK (Windows)
Page 28
Step 6: This step is only required for the HDC-302E . Select the transmitter bus (2 or 3)
(Figure 2-7). For example, when the Device0 button is selected to decode the
encoded file, please select 2 from the device2 (transmitter bus) drop-down
menu to display the video on HDMI display device via video output port. Please
refer to the following table:
Device Port Device4 (Transmitter Bus) Setting
Device0 2
Device1 3
Figure 2-6: Select Transmitter Bus for HDC-302E
Step 7: This step is only required for the HDC-304E . Select the transmitter bus from 4
to 7 (Figure 2-7). For example, when the Device0 button is selected to decode
the encoded file, please select 4 from the device4 (transmitter bus) drop-down
menu to display the video on HDMI display device by output kit. Please refer to
the following table:
Device Port Device4 (Transmitter Bus) Setting
Device0 4
Device1 5
Device2 6
Device3 7
