IOVU-751R-CE5/UX-R10 User Manual

Page 32

Step 9:

Secure the panel PC by fastening the retention screw of the wall-mounting

bracket. (

218H218H

Figure 4-11

).

Figure 4-11: Secure the IOVU-751R

4.3.2 Panel Mounting

The IOVU-751R-CE5/UX-R10 can be mounted in a panel.

CAUTION:

When mounting the IOVU-751R-CE5/UX-R10 take care to tighten the

retention screws or bolts until fully secure, but do not over tighten. Over

tightening the retention screws or bolts may cause them to become

stripped, rendering them useless.

To mount the IOVU-751R-CE5/UX-R10 into a panel, please follow the steps below.

Step 1:

Select the position on the panel to mount the IOVU-751R-CE5/UX-R10.
