4
MODEL SL575
• 1/2 HP Motor
Maximum Cycle Rate - 22 cycles per hour (At Maximum Gate Weight)
Maximum Gate Speed – 10"/sec. (25.4 cm/sec.)
Maximum Gate Weight – 1200 lbs. (544.3 kg)
Maximum Cantilever Gate Width – 25 ft. (7.6 m)
Maximum Overhead Roller Gate Width – 40 ft. (12.2 m)
Maximum V-Track Gate Width – 30 ft. (9.1 m)
28.9"
(73.4 cm)
27.5"
(69.9 cm)
37.7"
(95.8 cm)
14.1"
(35.8 cm)
19.5"
(49.5 cm)
14.9"
(37.9 cm)
17.2"
(43.7 cm)
10-7/8"
(27.6 cm)
O P E R A T O R D I M E N S I O N S A N D H O R S E P O W E R C H A R T
