For Emitter:
Function Status Meaning LED DIGIT
TEST
(green ON) Light curtain being tested, the OSSD status
on the receiver shall be OFF
Emission
(rated range)
(green ON
yellow ON)
Light curtain working and in normal
operating conditions
Normal
operation
Emission
(reduced range)
(green ON
yellow ON)
Light curtain working in normal operating
conditions
Function Type Check and repair LED DIGIT
Internal error
(green ON)
Switch OFF and switch ON the power
supply circuit. If the failure continues
contact DATASENSOR
Optical error
(green ON)
Switch OFF and switch ON the power
supply circuit. If the failure continues
contact DATASENSOR
Error status
No power supply
(LEDs OFF)
Check connections and input correct value.
If the failure continues contact
DATASENSOR
6
Receiver Emitter
Signals are clearly identified through symbols allowing immediate reading, independent of bars directions.
A short description of the signalling LEDs is necessary to avoid misunderstandings.
Two yellow LEDs ( LAST, SYNC) on SG2-E receiver, facilitates the alignment procedure.
During standard operation, the LEDs indicate the safety light curtain status, as shown in the table.
Correct alignment procedure
The light curtain alignment can be effected only after having completed the mechanical installation and the
electrical connections. The following procedure has to be followed:
NOTE: SG2-E is equipped with a system which informs the user on the alignment obtained.
The alignment function can be activated when powering the device, by keeping the normally open
RESET/RESTART contact closed for at least 0.5 seconds.
Display
LED
NORMAL
OP.
LED
SAFE
(BREAK)
LED
yellow
SYNC
LED
yellow
LAST
Condition
Alignment
Status
ON
Sync NOK
Last NOK
OFF
ON
Sync OK
Last NOK
OFF ON
OFF OFF
Sync OK
Last OK
Middle optics NOK
NO align.
ON OFF OFF OFF
Each beam is over the min.
operating threshold and the
number of beam over the
threshold is included between
0 and 25%
MINIMUM
align.
ON OFF OFF OFF
Each beam is over the min.
operating threshold and the
number of beam over the
threshold is included between
25 and 50%
ON OFF OFF OFF
Each beam is over the min.
operating threshold and the
number of beam over the
threshold is included between
50 and 75%
ON OFF OFF OFF
Each beam is over the min.
operating threshold and the
number of beam over the
threshold is included between
75 and 100%
MAXIMUM
align.
3
Last optics (LAST)
First optics (SYNC) =
synchronisation optics
NORMAL
OP.
NORMAL
OP.
SAFE(BREAK)
LAST
SYNC ON
