L
ON
W
ORKS
® Communication Module User’s Manual 4-3
4.2 Available network variables
The L
ON
W
ORKS
® Communication Module’s standard LON
application contains the network variables described below.
LonMark Node Object
Quantity Name Type Description
1 nviRequest0 SNVT_obj_request Request object mode
1 nvoStatus0 SNVT_obj_status Output object status
LonMark Controller Object
SNVT Description
SNVT_switch Switch light, alarm, window contact, free inputs / outputs
value=0, state=0
Þ inactive
value>0, state=1 Þ active
SNVT_occupancy Occupancy:0=occupied Þ 0
1=not occupied Þ 1
2=bypass Þ 0
3=standby Þ 1
SNVT_tod_event Scheduler program
Just current state: 0=occupied
3=standby
SNVT_temp_p Room temperature
SNVT_lux Brightness – lighting level
SNVT_lev_percent Position
