SAMPI MSA-15 Meter - Manual

Specifications
MSA-15 Meter
Liquid Controls Europe MS Series rotary motion positive
displacement (PD) meters offer the ultimate in measurement
accuracy for custody transfer of petroleum products,
aviation fuels, LPG and a broad of industrial liquids.
Superior performance features
Low pressure drop – will operate on gravity flow or pump
pressure.
Sustained accuracy – no metal-to-metal contact inside the
measuring chamber means minimal wear and deterioration
in accuracy over time, fewer recalibrations and a longer
service life. Meters conform to NIST and International
Weight and Measures accuracy requirements.
Wide viscosity range – LCE meters can accurately meter
products from less than 30 SSU (1 cP) to 1500000 SSU
(325000 cP).
Maximum adaptability - choice of stock or custom
elbows/fittings provides unequaled mounting flexibility to
meet widely varying installation requirements.
Accuracy/Performance
Repeatability
Mechanical registration: capable of 0.05% of reading over entire range
Electronic registration: capable of 0.03% of reading over entire range
Linearity
Over 5:1 range
Mech. registration: capable of ±0.125% or better from max nom. flow rate
Elect. registration: capable of ±0.10% or better from max. nom. flow rate
Over 10:1 range
Mech. registration: capable of ±0.22% or better from max. nom. flow rate
Elect. registration: capable of ± 0.10% or better from max. nom. flow rate
Over 40:1 range
Mech. registration: capable of ±0.5% or better from max. nom. flow rate
Elect. registration: capable of ±0.15% or better from max. nom. flow rate
Temperature range
-40° F to 160° F (-40° C to 71° C)
Industries served
LCE series SM meters are
well-suited for use in
industries requiring precise
flow measurement and
reliable, extended service
life:
• Refined petroleum
products
• Aviation fuels
• LPG
• Agricultural chemicals
• Paints and coatings
• Foods and beverages
• Petrochemicals
• Pharmaceuticals
• Cosmetics
• Printing inks
• Textiles
Construction
Meter housing and rotors
Cast aluminium (other
metallurgies, available
including brass, cast-iron
and stainless steel)
Internal components
Aluminium, Ni-Resist,
stainless steel
Seal materiale
UL recognize component:
Buna-N, Viton, Teflon
Bearings
Carbon, Teflon, Ni-Resist
