13

10.20 MODELS
2522C-05
2534C-01
2534C-02

Item

Qty.

Part No.

Description

Service Kit

SK668

Foot Kit

2500K-04

1

1

666469

Connecting Rod Ass’y

-

-

2

4

624266

Rubber Suction Feet

-

4

3

4

625175

Screw, Head

4

-

4

1

623143

O-ring, Head

1

-

5

1

621755-502

Valve Plate Ass’y

-

-

6

1

623071

O-ring, Cylinder

1

-

7

1

638816-502

Vacuum Gauge Ass’y

-

-

8

1

638955-502

Pressure Gauge Ass’y

-

-

9

1

638122

Pressure Gauge

-

-

10

1

638792

Vacuum Gauge

-

-

11

2

625094

Valve Flapper Screw

2

-

12

2

617562

Valve Keeper

2

-

13

2

621485

Valve Flapper

2

-

14

1

624396

Piston Cup

1

-

15

1

670031

Cylinder Sleeve

1

-
