Welch Vacuum 2546 WOB-L Pinston Pump User Manual
Page 12
12
Section 10: EXPLODED VIEWS AND PARTS LIST
10.10 MODELS
2546B-01
2546C-01
2546C-02
2546C-10
15
1
14
6
11
12
13
8
4
5
9
10
7
3
2
Item
Qty.
Part No.
Description
Service Kit
2546-03
Foot Kit
2500K-04
1
1
2546K-01
Connecting Rod Ass’y
1
-
2
4
2500K-04
Rubber Suction Feet
-
4
3
4
*
Screw, Head
4
-
4
1
*
O-ring, Head
1
-
5
1
2567K-02
Valve Plate Ass’y
-
-
6
1
*
O-ring, Cylinder
1
-
7
1
2522K-05
Vacuum Gauge Ass’y
-
-
8
1
2522K-06
Pressure Gauge Ass’y
-
-
9
1
726025
Pressure Gauge
-
-
10
1
726021
Vacuum Gauge
-
-
11
2
*
Valve Flapper Screw
2
-
12
2
*
Valve Keeper
2
-
13
2
*
Valve Flapper
2
-
14
1
*
Piston Cup
1
-
15
1
*
Cylinder Sleeve
1
-
* These parts are not available separately, but are supplied in service kits.
