SECTION 2
FBW-IOM-2014-0311
INSTALLATION
2-3
maintenance.
Adhere to the following for placement and rigging:
1. Locate in dry surroundings on a solid level base. Take note of the
dimensions given in Table 1.
2. Since an external electrical source is utilized, the boiler must be electrically
grounded in accordance with the National Electrical Code, ANSI/NFPA
70-latest edition.
3. Ensure that there is suffi cient room around the boiler to enable the
operator and the maintenance engineer to gain access to all parts of the
boiler.
4. Check location for ease of water supply and electrical connections. UL
requires at least 36” clear space be maintained in front of any electrical
panel.
5. Unit is crated for forklift transport. Do not allow weight to bear on any
equipment components.
Clearances and Serviceability
Adhere to the following for clearances and serviceability:
1. All local and national codes (NFPA, ANSI, UL, ETL, ASME) must be
followed for proper clearances and serviceability for your boiler or heater.
Authorities having jurisdiction should be consulted before installations are
made.
2. Appropriate front, back, side and top clearances must be maintained. This
will allow access around the equipment to facilitate maintenance and a
safe work environment. UL requires at least 36” clear space be maintained
in front of any electrical panel.
3. Ensure all labels on the boiler will be fully visible for maintenance and
inspection.
Boiler Trim
Each boiler is supplied with the following (supplied standard or fi tted to boiler).
Additional trim may be provided as ordered.
 Temperature/Pressure Gauge
 Low Water Cut Off (Probe Type)
 Water Relief Safety Valve (ASME Rated)
 Operating Aquastat
 High Limit Aquastat
!
WARNING
All information in this manual is for
reference and guidance purposes,
and does not substitute for required
professional training, conduct, and strict
adherence to applicable jurisdictional/
professional codes and regulations.
Competent personnel in accordance
with all applicable local codes should
carry out the installation of the Fulton
equipment. All state and jurisdictional
codes beyond the scope of the applicable
ASME Boiler and Pressure Vessel Codes,
for its corresponding classifi cation, should
be followed in all cases. Jurisdictional
authorities must be consulted prior to
installation.
A competent rigger experienced in
handling heavy equipment should handle
rigging your equipment into position.
The equipment must be installed on a
non-combustible surface.
Failure to provide required and safe
access to the equipment could impede
commissioning and maintenance.
Failure to provide proper minimum
clearances between equipment and
combustible materials may result in fi re.
4
CAUTION
Do not allow weight to bear on equipment
components to prevent damage.
