Alcatel OmniSwitch 6800 Family
10 Gig • OS6800-48, OS6800-U24, OS6800-48L support an optional two port 10 Gig module that
Uplinks plugs into the rear of the chassis. Each 10 Gig port supports industry standard, XFP based,
10 GigE optical transceivers.
Indicators • LEDs per port:
• 10/100/1000: speed, link/activity
• SFP: link/activity
• XFP: link/activity
• PoE ports: speed, link/activity/PoE applied
• System LEDs:
• System (OK) (chassis HW/SW status)
• PWR (internal power supply status)
• FAN (fan status)
• TEMP (overtemp)
• PRI (virtual chassis primary)
• BPS (backup power status)
• XFP 1 & 2 ( 10 Gig link status)
Physical • 17.32 x 16.73 x 1.73 in (W x D x H)
Dimensions • 44 x 42.5 x 4.4 cm (W x D x H)
Weight • OS6800-48, OS6800-48L: 14.41 lbs/6.54 Kg
• OS6800-24, OS6800-24L: 13.88 lbs/6.30 Kg
• OS6800-U24: 13.16 lbs/5.97 Kg
Connectors/ • Management: one RJ-45 console interface configured as DTE for operation, diagnostics,
Cabling status, and configuration information. Ship kit includes RJ-45 to DB-9 connector adaptor
• AC power connector and BPS connector slot on rear of chassis
Operating • Operating temperature: 0 to 45 C
Environment • Storage temperature: –20 to 70 C
• Operating relative humidity: 5 to 90% non-condensing
• Storage relative humidity: 0 to 95% non-condensing
Heat • OS6800-48, OS6800-48L: 635 Btu/hour
Dissipation • OS6800-24, OS6800-24L: 362 Btu/hour
• OS6800-U24: 386 Btu/hour
Acoustic • 50 dB for non-PoE switch, 55 dB for PoE switch; standard: ISO 7779: 1999(E)
MTBF • OS6800-48: 99,947 MTBF-Hr.
• OS6800-48L: 99,947 MTBF-Hr.
• OS6800-24: 131,489 MTBF-Hr.
• OS6800-24L: 131,489 MTBF-Hr.
• OS6800-U24: 132,805 MTBF-Hr.
Standards IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3x, IEEE802.3ab, IEEE802.3ae,
IIEEE802.1D, IEEE802.1q, IEEE802.3ad, IEEE802.1x, IEEE802.1w, IEEE802.1s, IEEE802.1p
Product Specifications
Features
