INSTEON Thermostat with Humidity (2441TH) Quick Start User Manual

Page 6

background image

3

Verify that the INSTEON Thermostat will

work with your air conditioning system.

Heat pump and line voltage systems are

incompatible.

W1/O/B

W2

M1SC1

RS2

M1SC3

RS+5

RS1

RS GND

Y1
G
M1SC2
CK1
CK GND
R
C

X
