Page 6 of 16 2453-222/2453-422/2453-522 - Rev: 1/21/2014 7:51 AM
Local Control Operations
DIN Rail’s switch operation mode affects how it responds to commands; so it’s important to properly program DIN
Rail for the correct type of switch you are installing. DIN Rail on/off buttons function exactly like the top and bottom of
your wall switch.
Note: LED will blink red for a few seconds if one or more responders do not acknowledge a message.
Latching Wall Switch (Default)
Note that this table refers to the latching switch operation if 3-way toggle mode is disabled (it is enabled by default).
Single Momentary Wall Switch
Dual Momentary Wall Switch
Adjust Local Settings
Change LED Brightness
DIN Rail’s LED is set at a default 50% brightness, but it can be set anywhere from off to 100% brightness by
following these steps.
1) Press and hold set button until it beeps
LED will start blinking green
2) Press and hold set button until it beeps a second time
LED will start blinking red
3) Press and hold set button until it beeps a third time
Connected load/responders
Latching switch Tap LED
Top
On
(ramped)
Green
Bottom
Off
(ramped)
Red
Connected load/responders
Single momentary switch Tap Double-tap LED
Switch
On/Off
(ramped)
On/Off
(instant)
Green/
Red
Connected load/responders
Dual momentary switch Tap Double-tap LED
Top
On
(ramped)
On
(instant)
Green
Bottom
Off
(ramped)
Off
(instant)
Red
