5) Slowly tap set DIN Rail button 3 times
LED will start double-blinking green
6) Press and hold DIN Rail set button (and don’t let go)
DIN Rail will begin a long beep
7) Release DIN Rail set button after beeping has stopped
After a few seconds DIN Rail will double-beep
DIN Rail will turn on and LED will turn green
X10 Setup
DIN Rail ships with no X10 address assigned.
Assign an X10 Address
1) Press and hold DIN Rail set button until it beeps
DIN Rail LED will start blinking green
2) Send the X10 address 3 times (with or without commands)
Example: A1-A1-A1-AON or A1-AON-A1-AON-A1-AON
DIN Rail will double-beep and its LED will stop blinking
3) Test by sending X10 on and off commands
Load will turn on and off
Remove X10 Address
1) Press and hold DIN Rail set button until it beeps
DIN Rail LED will start blinking green
2) Press and hold DIN Rail set button until it beeps a second time
DIN Rail LED will start blinking red
3) Send the X10 address 3 times (with or without commands)
DIN Rail will double-beep and its LED will stop blinking
4) Test by sending X10 on and off commands
Load will not respond
Specifications
General
Product name DIN Rail On/Off
Brand/manufacturer INSTEON
Manufacturer product number
US 2453-222
EU 2453-422
AUS/NZ 2453-522
UPC
US 813922012828
EU 813922012835
AUS/NZ 813922012842
Warranty 2 years, limited
INSTEON
INSTEON powerline mesh repeater Yes
INSTEON RF mesh repeater Yes
INSTEON controller Yes
INSTEON responder Yes
Maximum links/scenes 400
