4” hydraulic submersible, Sand / slurry pump, Features

background image

MODEL S4CSL

4” (100 mm) Discharge

4” HYDRAULIC SUBMERSIBLE

SAND / SLURRY PUMP

with AGITATOR

The S4CSL pump is designed to use in

applications requiring settled solids to be put

into suspension and pumped with the

discharge water. Primary applications include

de-silting ponds, lakes and streams. Other

jobs may include filling sand bags to prevent

beach erosion, tank and digester cleaning or

pumping sediment from caissons.

FEATURES

C0413

167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website

:

www.hydra-tech.com

E-Mail

:

[email protected]

SPECIFICATIONS

Specifications are subject to change without notice

Hardened Alloy Wear Parts

Built-in Agitator for stirring up solids

Oil Lubricated Seals (can run dry)

Variable Speed hydraulic drive

Small Size allows pump to fit through a
17 inch opening

Safe Hydraulic Drive can be used where
electric power is hazardous or impractical

Dependable gear type hydraulic motor

Operates with our HT20 to HT35 power
units or other hydraulic power sources
capable of flows to 17 GPM

WEIGHT:.......................................... 273 lbs. (124 kg)
HEIGHT:................................................... 31" (79 cm)

WIDTH (@ widest point):....................16 1/4" (41 cm)
DISCHARGE:................................................. 4" NPT

SOLIDS HANDLING:......................... 1 1/2" (38 mm)
HOSE PORTS:..........................1/2" and 3/4" NPT (F)

VOLUTE*:................................ Hardened Ductile Iron
IMPELLER:................................... High Chrome Alloy

WEAR PLATE............................... High Chrome Alloy
AGITATOR:.................................. High Chrome Alloy

SHAFT:........................................ 304 Stainless Steel
SHAFT SEALS: (upper)................... Carbon/Ceramic

(Lower)..................... Silicon Carbide
HYDRAULIC OIL:...... 214-320 s.s.u. @ 100°F (64°C)

INPUT FLOW:........................ Max 17 GPM (64 LPM)
OPERATING PRESSURE:... Max 2800 PSI (190 Bar)

POWER SOURCE:..

Any Open Center Hydraulic System

* Optional NI-Hard volute available for highly abrasive applications
