MODEL S8T
8” (200 mm) Discharge
8” HYDRAULIC SUBMERSIBLE
VORTEX FLOW TRASH PUMP
The S8T is a vortex flow pump
designed to provide reliable high
volume pumping on jobs ranging from
wastewater to sewage to sludge and
debris laden applications. Its ability to
pass large semi-solids allows more
shear sensitive materials to be
pumped with less degradation.
FEATURES
E0413
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
: www.hydra-tech.com E-Mail : [email protected]
WEIGHT:..................................................... 536 lbs. (243 kg)
HEIGHT:............................................................ 42" (107 cm)
WIDTH (@ widest point):.............................. 33 3/4" (86 cm)
DISCHARGE:........................................ 8" 125# ASA Flange
INLET:.................................................... 8" 125# ASA Flange
SOLIDS HANDLING:............................................ 7" (17 cm)
HOSE PORTS:................................. 1 1/4" or 1 1/2" NPT(F)
PUMP BODY:..................................................... Ductile Iron
IMPELLER:......................................................... Ductile Iron
WEAR RING and WEAR PLATE:.............. ASTM A36 Steel
SHAFT:.............................................17-4 PH Stainless Steel
SHAFT SEAL:............................................... Silicon Carbide
ELASTOMERS:................................................ Buna N (Std)
HYDRAULIC OIL:................ 214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:................................. Max 70 GPM (265 LPM)
OPERATING PRESSURE:............. Max 2800 PSI (190 Bar)
POWER SOURCE:....... Any Open Center Hydraulic System
SPECIFICATIONS
Specifications are subject to change without notice
•
Recessed Vortex Impeller
(will pass 7" semi-solids)
•
Compact Design allows this pump to fit
through a 34” opening
•
Variable Speed hydraulic drive provides
a wide range of performance
•
Oil Lubricated Seals (can run dry)
•
High Efficiency Balanced Vane
hydraulic motor
•
Can be bolted directly into a pipeline or
used as a booster pump
•
Safe Hydraulic Drive can be used where
electric power is hazardous or
impractical
•
Operates with our HT100 to HT150
power units or other hydraulic power
sources capable of flows of 50 - 70 GPM
