MODEL S3A
3” (75mm) Discharge
3” HYDRAULIC SUBMERSIBLE
SLIM-LINE PUMP
The S3A is designed to be used as a
dewatering pump in areas where space
is limited . Typical uses for this pump
include manhole, vault, blasthole, mine
and construction jobsite dewatering.
FEATURES
•
Hardened Stainless Steel Impeller resists
wear
•
Rubber Coated Suction Case resists
abrasion
•
Small Overall Size allows pump to fit
through 8" diameter opening
•
Oil Lubricated Seals (can run dry)
•
Variable Speed hydraulic drive
•
Safe Hydraulic Drive can be used where
electric power is hazardous or impractical
•
Dependable gear type hydraulic motor
•
Operates with our HT15 to HT25 power
units or other hydraulic power sources
capable of flows to 12 GPM
B0109
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
: www.hydra-tech.com E-Mail : [email protected]
WEIGHT: ............................................. 41 lbs. (19 kg)
HEIGHT:........................................... 19 3/4" (50 cm)
DIAMETER:......................................... 7 1/2" (19 cm)
DISCHARGE:............................................ 3", NPT(F)
SOLIDS HANDLING:............................... 1/4" (7 mm)
HOSE PORTS:....................................... 1/2" NPT (F)
PUMP BODY:............................. Anodized Aluminum
IMPELLER:........................... 17-4 PH Stainless Steel
SUCTION CASE: ................................. Rubber Lined
WEAR PLATE: ...................................... Polyethylene
SHAFT:............................................... Stainless Steel
SHAFT SEAL:.................................... Silicon Carbide
ELASTOMERS:..................................... Buna N (Std)
HYDRAULIC OIL:..... 214-320 s.s.u. @ 100°F (64°C)
INPUT FLOW:...................... Max. 12 GPM (45 LPM)
OPERATING PRESSURE:. Max. 2300 PSI (156 Bar)
POWER SOURCE:.. Any Open Center Hydraulic System
SPECIFICATIONS
Specifications are subject to change without notice
