15
Event notification: Notify to FTP, email, Samba server or Digital output triggered.
Update: Support Firmware update.
Browse
I.E. 7.0 above; Safair Browser, Fire fox and Chrome V3.0 above with plug in.
Housing
Mental Housing
Dimension/Weight
148mm (L) x 78mm (W) x 78 mm (H) / 0.65Kg
Operation
Power: Maximum 3 W; PoE IEEE 802.3af Class 3; DV12V
Temperature: Temperature -10°C ~ 50°C; Humidity 20% ~ 80% RH.
EC-3MIPW
System
Platform: TI DM368 SoC CPU; Linux Embedded O.S.
Image Device
1/3" 3 M pixels (2048x 1536 pixels) progressive CMOS sensor.
Video Setting
Compression: Video: 0.1M ~ 12M bits/sec (CBR/VBR/LBR configurable) H.264
HP/MP/BP, M-JPEG; Audio: G.711
μ-low/a-low Codec
Resolution: Main Streaming: 2048Ч1536, 1920Ч1080, 1280Ч720.
Sub streaming: 320×288, 320*240
Frame Rate: 3-Mega: 20 fps; 1080p: 30 fps @ H.264/M-JPEG Mode; Frame rate can be
adjustable by user.
Streaming: Multi-Stream H.264 Base/Main/High Profile and Motion JPEG video streaming
Control: Brightness, Contrast, Saturation, Sharpness, Exposure, Motion detection, Mirror,
Shutter, Privacy mask, Flickerless, Noise reduction, IRIS, AES, AWB, AGC, BLC, WDR,
ROI, Audio gain, Alarm in/out
Color: 0.2 Lux 1/F1.2 B/W: 0.1 Lux .
