8. Montaggio:
a.
Posizioni e prema l’alloggiamento scheda in
posizione corretta.
(figura finestra DIN destra; il montaggio DIN
sinistra è analogo!)
b.
applichi la base di montaggio:
i fori per le viti di fissaggio devono puntare
verso il muro!
distanza dal bordo della finestra: 10 mm
(figura finestra DIN destra; il montaggio DIN
sinistra è analogo!)
10 mm
