ABUS FUMK50020 Secvest Mini Wireless Magnetic Contact Detector User Manual
Page 33
– 32 –
– 33 –
8. Montage :
a.
Placez correctement le boîtier porte-carte
et appuyez.
(Illustration fenêtre DIN à droite, pour un
montage DIN à gauche agissez par analogie !)
b.
Monter le socle à vis :
Les trous des vis de fixations doivent être
orientés vers le mur !
distance par rapport au bord de la fenêtre :
10 mm
(Illustration fenêtre DIN à droite, pour un
montage DIN à gauche agissez par analogie !)
10 mm
F
MoAnLtg. Mini-Funk-Oeffnungsmelder_100x90mm_NEU.indd 33
20.04.12 08:54
