AcuTab-M

Quick Guide












Acura Embedded Systems Inc.





Main Features

Platform: Intel® Cedar Trail Platform (N2600+NM10)
GPU: Intel ATOM N2600 1.6GHz Dual core
Chipset: Intel® NM10 Express Chipset
System Memory: 2GB DDRIII 800 SO-DIMMM
Storage: 1 x 32G SATA Slim Half-Size Solid State Disk
LCD Panel: 10.4-inch LED Backlight Screen

10.4“ XGA (1024x768) 340nits LCD + T/P(Polarizer + 1/4 λ+ AR)

Touch Panel

5-wire Resistive Touch Screen

Audio: -1 x High Quality Speaker (2W)
-Internal Microphone : 1 x in front Bezel
TPM:

1 x Compatible with TPM1.2 (option)

Communication :

- 10/100Mbps Ethernet (via adapter to mini USB port)
- Wi-Fi IEEE 802.11 a/b/g/n; Bluetooth 4.0
- 3G,4G LTE(Optional)
- Webcam:

Front - 2 Mega-pixel Camera
Rear - 5 Mega-pixel Camera with LED Flash light

- Automatic Focus
- Automatic white balance Power

Adapter :

AC Input, 100V ~ 240VAC, 50~60Hz
DC Output, [email protected], 65W

Battery

Internal Battery - Smart Lithium Polymer Battery, 3800mAH, 7.4V

Mechanical & Environmental

Dimension

277.8 x 206 x 26.5mm

Weight

1.1kg

Operation System

OS

Windows 7 Pro, WES7P 32bit

Rugged Design

Drop

6ft drop ploywood on concrete

Water/Dust Resistance

IP65

Environment

Operation temperature

-20°C to +50°C

Storage Temperature

-30°C to +70°C

Humidity

5-95% without condensation
