Acura Embedded AcuTab-W - Manual

AcuTab 2 Standard Quick Setup Guide
Getting Started
1. Plugging the Power Cable
(Figure1)
a. Plug the AC power cord in to the power
socket of the AC power adapter
b. Plug the other end of the AC power
cord to a live AC wall outlet
c. Plug the connector of the AC adapter
to the DC-IN port found at the left side
of the AcuTab2 System.
2. Turning on the AucTab 2 System
(Figure2)
To turn on the AucTab 2 System, press
the power button. The power LED will
light upt o indicate that the AucTab 2
System is on
Figure1
Figure2
Main Packing List
Main system
Power Adapter
Corner Rubber
Stylus
Accessories(Option)
Barcode Scanner
Vehicle Docking
Battery Charger
Carrying Bag
QTY
1
1
4
1
QTY
1
1
1
1
Utilities CD
Power Cord
Shoulder Strap
Hook Screw
MSR
Vehicle Bracket
GPS
Handle Secures
QTY
1
1
1
6
QTY
1
1
1
Quick Setup Guide
Corner Rubber Screw
Hand Strap
Desiccant
Desk Top Docking
Vehicle Power Adapter
GPS/GPRS Tracker
More
QTY
1
4
1
1
QTY
1
1
1
Exploring Your AcuTab 2 System
Over look of the AcuTab 2 System Front Side of the AcuTab 2 System
Bottom Side of the AcuTab 2 System
1. Docking Connector
1. Camera/1.3 Mega-pixel
2. Digital Microphone
3. LED Power/Storage/Wi-Fi
4. Light Sensor
5. Barcode Button
6. Navigation Buttons
7. RFID
8. User Interface Button
9. Program Function Buttons
10. Barcode Button
