34 105SL User Guide 6/4/2004 11342L Rev. 8
Printer Operation
Print a Network Configuration Label
Print a Network Configuration Label
If you are using a print server, you can print a network configuration label after the printer is
hooked to the network. A network configuration label lists the settings for the ZebraNet wired
print server and the ZebraNet Wireless Print Server (if installed).
To print a network configuration label, complete these steps:
1. From the front panel, press SETUP/EXIT.
2. Scroll through the parameters until you reach LIST NETWORK .
3. Confirm printing.
A network configuration label prints (
Figure 28 ).
Figure 28 • Network Configuration Label
Important • To operate the Wireless Print Server, your 105SL printer must:
• have a serial number greater than 6400356
• have the wireless PCMCIA board installed
• be running firmware version V60.13.X or higher
